Shallow Water F4 Console

Features & Options

  • .125 Aluminum Hull (5086)
  • Optimal 17-degree transoms for superior mud motor trim control
  • Full Flat Floor
  • Triple Taper Chine
  • Longitudinal Full Length 2″ X 4″ Ribs – 6063 Alloy
  • High Transom Only
  • F4 Transom Step Deck
  • Extruded Gunwale (w/rubber rub rail and slotted interior for accessory mounting)
  • Bow Rails
  • Full Flotation
  • High Front Deck
  • Front Deck Storage with Mesh Panel Cover
  • Aluminum Center Console with Windshield & Heavy Duty Grab Rail, 12V Plug, Rocker Switches and Breakers
  • Driver’s Storage Box with Tempress Seat
  • Navigation Lights
  • Aluminum Center Console with Windshield & Heavy Duty Grab Rail, 12V Plug, Rocker Switches and Breakers
  • Bilge 800 GPH
  • Rear Hand Rails
  • Camo (Optifade™ Marsh, Optifade™ Timber, Max-4, Natural Gear Green and Brown & Old School)
  • Built-In Bow 3,000lb KFI Winch
  • Twin 5800 Lumen LED Headlights
  • Interior LED Lighting (White, Blue, Red or Green LED’s)
  • Trolling Motor Kit w/Harness, Plug and Battery Tray
  • Built-In 11 Gallon Fuel Tank
  • Cup & Shell Holder
  • Spud Poles
  • 26 Quart ORCA Cooler with Seat Cushion (driver’s seat exchange)
  • Full Line of Minnkota Trolling Motors
  • Mud Buddy Shallow Water Motors w/Hydraulic Steering
  • Outboard Motors Can Be Used on This Model
  • Optifade™ Camo Upholstery
  • Bluetooth Stereo
  • Turtlebox Speaker
  • Kik-Up Transom (Available with outboard only)
  • Traditional Gun Box


1854 | 18′

Hull Thickness (5086)
1854 | .125

1854 | 54″

Max HP
1854 | 70

1854 | 69″

1854 | 735 lbs.

Capacity Person/Lbs
1854 | 4/560

Transom Height
1854 | 20″

Gunwale Height
1854 | 25″

F4 Step Deck Console

Excel shallow water boats with the triple taper chine roll into turns with limited slip. These hulls plane quickly, turn on a dime and are specifically designed for shallow water surface drive mud motors. Coupled with our F4 step deck, nothing matches the performance of this hull in shallow water.

Triple Taper Chine

Built-In Fuel Tank

The optional built-in 11 gallon fuel tank is a convenient add on feature for your new Excel boat. Included is a front deck mesh cover with two storage pockets. The tank filler is located on the front deck for easy access.

LED Headlight Option

The twin LED 5800 lumen headlight guides you through the darkest marshes or timber. The lights can be adjusted upwards or downwards as needed for your boat design, and the lights rotate around for backing the boat. Turn the light to the side to put out your decoys.

The headlight switch is located on the driver control panel.

Electric Shift F-N-R

WOW – electric shift reverse. And all in one handle. The Mud Buddy mercury style shifter has the trim, throttle and electric shifter all in one place. So simple, just move the shifter forward or back and it shifts, a little more and throttle up. Sweeeet…

Orca Cooler Option

This 75 quart quality Orca high performance cooler mounts in front of the center console. The floor mount and tie downs keep it in place for your drinks, fish and snacks on those long runs and hot days. Hunters like the cooler which keeps their lunch and refreshments from freezing when snow is blowing sideways. And, the lockable Orca is great waterproof storage box for your valuables.

1854 Shallow Water F4 Console

Tubular 1/4″ Bow

This boat is darn tough. The 1/4″ tubular bow on the F4 Console is the toughest of any production or custom hardcore duck boat. The hull is .125 thick and built from hardened 5086 aluminum, the strongest aluminum that can be formed into a boat.
